Features
| MPPT Solar Charger | |
| MPPT QTY | 2 |
| Solar Operating | 20-60V |
| MPPT Operating | 25-60V |
| Max. PV open circuit voltage | 60Vdc |
| Max. PV array Power | 2 x 1 Tracker 600W |
| Max. Charging Current | 50A |
| Max. DC load Current | 2 x 30A@45V |
| Self Consumption | 2W |
| MPPT Tracking Efficiency | 99.90% |
| Conversion Efficiency | 98% |
| Protection | overload, reverse connection, short circuit, high voltage ,high temperature protection |
| Battery | |
| Battery Type | Sealed , AGM, Gel, Flooded, Lithium , Lithium carbonate, User-defined |
| Battery Voltage | Standard 24V |
| Battery Voltage Range | 10V-60V |
| Customized Discharge Time | Set up the discharge time by APP |
| Communication | |
| Communication Port | RS485 |
| Energy Management | |
| Input Power form Micro inverter | 1.6KW |
| Suggested Microinverter | 2PCS*800W inverter or 1 PCS 1000~1600W inverter |
| AC Loading (Back-up) | 1.2KW @230VAC( 2PCS*800W Inverter Input) |
| Loading Peak Power (Back-up) | 3.6KW (with 1pc 1.2KW inverter) |
| AC Output (on-grid) | 1.2KW @230VAC (1pc 1.2KW Inverter Input) (depends on PV and inverter rated power) |
| Output Power Factor (Adjustable) | >0.99 Default, 0.8 Leading...0.8 Lagging... |
| UPS Switch Time | <10mS |
| Level of Harmonics Distortion | THD <3% |
| Protection | overload, short circuit, battery low voltage, battery reverse polarity, Island protection |
| Mechanical | |
| Net weight & Gross weight | 3KGS /4KGS |
| Dimensions & Packing | 232*301*90 MM |
| Cooling | Natural Convection-No Fans |
| Enclosure | IP65 |
| Environment | |
| Ambient Temperature | -25~65℃ ( Derating from 45℃) |
| Storage Temperature | -40℃~+85℃ |
| Humidity | 100% non-condensing |
| Warranty | 3 Years |
| Certification | |
| Safety | CE ROHS FCC |
| P.K. Size | 400*350*100mm |
| G.W | 4KGS |
